Ameba ARDUINO: Peripherals & Examples

Peripheral Library & Examples

Components used in Examples ​

Adafruit 2.8” TFT LCD Touch Shield

ILI9341 TFT LCD display, touch screen with built in microSD card connection. Support SPI.

Adafruit Ultimate GPS Breakout

High-quality GPS positioning module with -165 dBm sensitivity, 10 Hz updates, 66 channels.

AS606 Fingerprint Module

Fingerprint Scanner working by 5V power.

DHT11 / DHT21(AM2301) / DHT22(AM2302)

Low cost temperature & humidity sensors working by 3 to 5V power and I/O.

Dragino LoRa SX127x Shield

Long range transceiver.

DS1307

Low-power serial real-time clock. Supports I2C.

DS3231

Low-power serial real-time clock. Supports I2C.

DS18B20

1-Wire Digital Temperature Sensor.

Grove - Infrared Emitter

The Infrared Emitter is used to transmit infrared signals through an infrared LED.

Grove - Infrared Receiver

The Infrared Receiver is used to receive infrared signals and also used for remote control detection.

I2C 2×16 LCD

2×16 LCD display screen with I2C interface.

L298N H-Bridge

Motor controller module

Logitech C170 Webcam

Usb 2.0 Webcam.

MPU6050

6-Axis (Gyro + Accelerometer) MotionTracking Devices. Support I2C.

PlanTower PMS3003 / PMS5003

Air quality sensor that detects concentration of micro particulate matters.

QVGA 2.2" TFT LCD

ILI9341 TFT LCD display, with built in microSD card connection. Support SPI.

Realtek ALC5680 Audio Shield

Audio Codec Shield working by I2S

RFID-RC522

RFID reader/writer IC for contactless communication.

Sparkfun HTU21D

Temperature & Humidity Sensor.

SparkFun SX1509 I/O Expander

16-channel GPIO expander with an I2C interface.

Tower Pro SG90

Tiny and lightweight servo with high output power.

Ultrasonic Distance Sensor - HC-SR04

Ultrasonic distance sensor module.

USB to TTL Adapter

The USB TTL Serial cables are a range of USB to serial converter cables which provide connectivity between USB and serial UART interfaces.

WS2812 LED (4*4)

Intelligent control LED integrated light source.
